Compatible media size

Letter/A4/A3/A3 Plus (Vertical only)

Maximum number of media that can be loaded

100 sheets (thick paper) to 150 sheets (thin paper)

* Even if the maximum number of media sets is within the range, the total weight must be 4.5 kg or less.

Compatible media

Tack paper (for laser printer)

Thickness 0.15 to 0.23 mm (157 to 181 g/m2)

* Basis weight is for reference only

* Static electricity generating media and copy paper, etc. are not available.

Operating environment

15°C to 30°C 70% (no condensation)

Curl Tolerance

5 mm or less

External dimensions (approx.)

(when used at 45-degree) (W × D × H)

677 × 1230 × 633 mm

Table height 470 mm or more

External dimensions (approx.)

(when used on a tabletop) (W × D × H)

677 × 1360 × 326 mm

ASF1-30 Body Weight (approx.)

7.2 kg

Weight of paper eject section (approx.)

6.6 kg
